pCAG-mIRFP670nuc-TEV-Xph20-ETWV
(Plasmid #133044)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 133044 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pCAG-miRFP670nuc
  • Backbone size w/o insert (bp) 7723
  • Total vector size (bp) 8140
  • Modifications to backbone
    Home-made vector derived from pCAG, which produces in frame a mIRFP670 reporter fused to NLS sequences, the TEV protease and the TEV cleavage site followed by the protein of interest.
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    Xph20-ETWV
  • Species
    Synthetic
  • Insert Size (bp)
    417
  • Mutation
    S63K
  • Promoter CAG
  • Tags / Fusion Proteins
    • miRFP670 (N terminal on backbone)
    • NLS (N terminal on backbone)
    • TEV protease + TEV cleavage site (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site BsrGI (not destroyed)
  • 5′ sequencing primer pCAG-F
  • 3′ sequencing primer WPRE-R
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCAG-mIRFP670nuc-TEV-Xph20-ETWV was a gift from Matthieu Sainlos (Addgene plasmid # 133044 ; http://n2t.net/addgene:133044 ; RRID:Addgene_133044)
  • For your References section:

    Engineering selective competitors for the discrimination of highly conserved protein-protein interaction modules. Rimbault C, Maruthi K, Breillat C, Genuer C, Crespillo S, Puente-Munoz V, Chamma I, Gauthereau I, Antoine S, Thibaut C, Tai FWJ, Dartigues B, Grillo-Bosch D, Claverol S, Poujol C, Choquet D, Mackereth CD, Sainlos M. Nat Commun. 2019 Oct 4;10(1):4521. doi: 10.1038/s41467-019-12528-4. 10.1038/s41467-019-12528-4 PubMed 31586061
