CIRTS-1: ORF5-TBP6.7-Pin domain-NLS
(Plasmid #132543)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 132543 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    cmv d0
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    CIRTS-1: ORF5-TBP6.7-Pin domain-NLS
  • Species
    Synthetic
  • Promoter cmv d0
  • Tag / Fusion Protein
    • FLAG tag (C terminal on insert)

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer AGTTAAATTGCTAACGCAGTCA
  • 3′ sequencing primer CAGCAGCCAACTCAGCTTCCTTTCGGGCTT
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    CIRTS-1: ORF5-TBP6.7-Pin domain-NLS was a gift from Bryan Dickinson (Addgene plasmid # 132543 ; http://n2t.net/addgene:132543 ; RRID:Addgene_132543)

  • For your References section:

    Programmable RNA-Guided RNA Effector Proteins Built from Human Parts. Rauch S, He E, Srienc M, Zhou H, Zhang Z, Dickinson BC. Cell. 2019 Jun 27;178(1):122-134.e12. doi: 10.1016/j.cell.2019.05.049. Epub 2019 Jun 20. 10.1016/j.cell.2019.05.049 PubMed 31230714
