p3xFLAG CMV14 / BRAF-D594E
(Plasmid #131714)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 131714 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    p3xFLAG-CMV-14
  • Backbone manufacturer
    Sigma-Aldrich
  • Backbone size w/o insert (bp) 6310
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    BRAF
  • Alt name
    B-RAF
  • Alt name
    ENSG00000157764
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    2301
  • Mutation
    D594E
  • Entrez Gene
    BRAF (a.k.a. B-RAF1, B-raf, BRAF-1, BRAF1, NS7, RAFB1)
  • Promoter CMV
  • Tag / Fusion Protein
    • 3xFLAG (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Unknown (unknown if destroyed)
  • 3′ cloning site Unknown (unknown if destroyed)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    p3xFLAG CMV14 / BRAF-D594E was a gift from Jacques De Grève (Addgene plasmid # 131714 ; http://n2t.net/addgene:131714 ; RRID:Addgene_131714)

  • For your References section:

    Non-V600 BRAF mutations recurrently found in lung cancer predict sensitivity to the combination of Trametinib and Dabrafenib. Noeparast A, Teugels E, Giron P, Verschelden G, De Brakeleer S, Decoster L, De Greve J. Oncotarget. 2016 Aug 26;8(36):60094-60108. doi: 10.18632/oncotarget.11635. eCollection 2017 Sep 1. 10.18632/oncotarget.11635 PubMed 28947956
