pORANGE CACNG2-GFP KI
(Plasmid #131504)

• Purpose: Endogenous tagging of Tarpγ2/Stargazin: Intramolecular (amino acid position: S265)
• Depositing Lab: Harold MacGillavry
• Publication: Willems et al PLoS Biol. 2020 Apr 10;18(4):e3000665. doi: 10.1371/journal.pbio.3000665.

Backbone

• Vector backbone: pORANGE
• Backbone size w/o insert (bp): 9243
• Vector type: Mammalian Expression

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: gRNA and GFP donor
• gRNA/shRNA sequence: GCTTCAACACCCTGCCGTCCA
• Species: M. musculus (mouse), R. norvegicus (rat)
• Entrez Gene: Cacng2 (a.k.a. Ipr328)
• Entrez Gene: Cacng2 (a.k.a. B230105C07Rik, B930041E13Rik, stargazer, stargazin, stg, wag, waggler)
• Promoter: U6 and Cbh

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: Unknown (unknown if destroyed)
• 3′ cloning site: Unknown (unknown if destroyed)
• 5′ sequencing primer: aaggctgttagagagataattggaa
• 3′ sequencing primer: cgggccatttaccgtaagtt

Resource Information

• Supplemental Documents:
  • pORANGE CACNG2-GFP KI.gb

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry
