pAAV_Donor/Reporter-COL4A3
(Plasmid
#130279)
-
PurposeCOL4A3 mutation-specific sgRNA under the control of U6 promoter; mCherry-sgRNA target-(out of frame)EGFP expression cassette; COL4A3 donor template
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 130279 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepAAV2.1
- Backbone size w/o insert (bp) 5419
- Total vector size (bp) 6948
-
Vector typeAAV
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)NEB Stable
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namemCherry-eGFP
- Promoter CMV
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site AflII (not destroyed)
- 3′ cloning site NotI (not destroyed)
- 5′ sequencing primer cgtggatagcggtttgactc
- 3′ sequencing primer TTCAGGTTCAGGGGGAGGTG (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pAAV_Donor/Reporter-COL4A3 was a gift from Silvestro Conticello (Addgene plasmid # 130279 ; http://n2t.net/addgene:130279 ; RRID:Addgene_130279) -
For your References section:
New frontiers to cure Alport syndrome: COL4A3 and COL4A5 gene editing in podocyte-lineage cells. Daga S, Donati F, Capitani K, Croci S, Tita R, Giliberti A, Valentino F, Benetti E, Fallerini C, Niccheri F, Baldassarri M, Mencarelli MA, Frullanti E, Furini S, Conticello SG, Renieri A, Pinto AM. Eur J Hum Genet. 2019 Nov 21. pii: 10.1038/s41431-019-0537-8. doi: 10.1038/s41431-019-0537-8. 10.1038/s41431-019-0537-8 PubMed 31754267
