pcDNA3.1-mCherry-CyrCR1.miR17
(Plasmid #128748)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 128748 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone size w/o insert (bp) 5300
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Cyrano conserved region (CR1) with miR-17 site replacing miR-7 site
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    200
  • Entrez Gene
    OIP5-AS1 (a.k.a. cyrano, linc-OIP5)
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NotI (not destroyed)
  • 3′ cloning site XbaI (not destroyed)
  • 5′ sequencing primer T7
  • 3′ sequencing primer BGH REV
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1-mCherry-CyrCR1.miR17 was a gift from David Bartel (Addgene plasmid # 128748 ; http://n2t.net/addgene:128748 ; RRID:Addgene_128748)

  • For your References section:

    A Network of Noncoding Regulatory RNAs Acts in the Mammalian Brain. Kleaveland B, Shi CY, Stefano J, Bartel DP. Cell. 2018 Jul 12;174(2):350-362.e17. doi: 10.1016/j.cell.2018.05.022. Epub 2018 Jun 7. 10.1016/j.cell.2018.05.022 PubMed 29887379
