pSB4C5_J23101-vdh
(Plasmid #128130)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 128130 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pSB4C5 (iGEM registry)
  • Vector type
    Bacterial Expression, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 7 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    vdh
  • Alt name
    Aryl-aldehyde oxidase (EC: 1.2.3.9), UniProtKB - D0RZT4
  • Species
    From Acinetobacter johnsonii SH046, codon optimized for E. coli
  • Promoter J23101

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BsaI, golden gate (unknown if destroyed)
  • 3′ cloning site BsaI, golden gate (unknown if destroyed)
  • 5′ sequencing primer ATACGCAAGGCGACAA
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pSB4C5_J23101-vdh was a gift from Jean-Loup Faulon (Addgene plasmid # 128130 ; http://n2t.net/addgene:128130 ; RRID:Addgene_128130)

  • For your References section:

    Metabolic perceptrons for neural computing in biological systems. Pandi A, Koch M, Voyvodic PL, Soudier P, Bonnet J, Kushwaha M, Faulon JL. Nat Commun. 2019 Aug 28;10(1):3880. doi: 10.1038/s41467-019-11889-0. 10.1038/s41467-019-11889-0 PubMed 31462649
