pSB4C5_pBen-BenR
(Plasmid
#128127)
-
PurposeExpressing BenR transcription factor gene under control of benzoate responsive promoter (pBen) in a feedback loop.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 128127 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepSB4C5 (iGEM registry)
-
Vector typeBacterial Expression, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Chloramphenicol, 7 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberLow Copy
Gene/Insert
-
Gene/Insert nameBenR
-
SpeciesPseudomonas putida
-
Insert Size (bp)957
- Promoter pBen
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site BsaI, golden gate (unknown if destroyed)
- 3′ cloning site BsaI, golden gate (unknown if destroyed)
- 5′ sequencing primer ATACGCAAGGCGACAA (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please note: Plasmid contains a single C nucleotide insertion in the pBen promoter sequence. It is not known if this mutation affects plasmid function.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pSB4C5_pBen-BenR was a gift from Jean-Loup Faulon (Addgene plasmid # 128127 ; http://n2t.net/addgene:128127 ; RRID:Addgene_128127) -
For your References section:
Metabolic perceptrons for neural computing in biological systems. Pandi A, Koch M, Voyvodic PL, Soudier P, Bonnet J, Kushwaha M, Faulon JL. Nat Commun. 2019 Aug 28;10(1):3880. doi: 10.1038/s41467-019-11889-0. 10.1038/s41467-019-11889-0 PubMed 31462649
