INCTbiosyn-p35S(rc)2_4_5-GFP
(Plasmid #127520)

• Purpose: Plasmid has an inverted CaMV 35S promoter sequence (reverse complement) flanked by attB and attP attachment sites of integrases 2, 4, and 5. EGFP coding sequence is in the forward orientation.
• Depositing Lab: Martin Bonamino
• Publication: Gomide et al Commun Biol. 2020 May 22;3(1):255. doi: 10.1038/s42003-020-0971-8.

Backbone

• Vector backbone: pUC18
• Vector type: Plant Expression

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: CaMV 35S reverse complement promoter sequence flanked by attB/attP Integrase 2, 4 and 5 attachment sites.
• Alt name: promoter Switch vector INTs 2_4_5
• Species: A. thaliana (mustard weed)
• Insert Size (bp): 1793

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: Unknown (unknown if destroyed)

Resource Information

• Article Citing this Plasmid:
  • 1 Reference

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Depositor Comments

The CaMV 35S promoter in a reverse complement sequence orientation came from iGEM registry (BBa_K1547006 ) and the attB/P integrases 2, 4 and 5 attatchment sites flanking this sequence came from Yang, L. et al. Nat. Methods 11, 1261-1266 (2014). This cassete was previously synthesized in pBluescript II SK(-) and after cloned using HindIII and BamHI replacing the forward CaMV 35S promoter sequence from a 35S-GFP plasmid construction of Chiu, W. et al. Curr. Biol. 6, 325-330 (1996).
