pHybr_r2a>Fab-srt-his
(Plasmid
#124810)
-
PurposeHDR template to knock-in sortag and histag in rat IgG2a heavy chain locus. Use in combination with PX459-gR2A_Hinge to convert rat IgG2a hybridoma to Fab' fragment producing cell lines.
-
Depositing Labs
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 124810 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepCR4 TOPO TA
-
Backbone manufacturerThermo Fisher
- Backbone size w/o insert (bp) 3956
- Total vector size (bp) 6317
-
Vector typeBacterial Expression, CRISPR ; HDR template
-
Selectable markersBlasticidin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin and Kanamycin, 100 & 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert namerat IgG2a Hinge-G4S-Sortag-Histag
-
SpeciesR. norvegicus (rat)
-
Insert Size (bp)2360
- Promoter pUC
-
Tags
/ Fusion Proteins
- Sortag (LPETGG) (C terminal on insert)
- Histag (HHHHHH) (C terminal on insert)
Cloning Information
- Cloning method TOPO Cloning
- 5′ sequencing primer CAGGAAACAGCTATGAC
- 3′ sequencing primer GTAAAACGACGGCCAG (Common Sequencing Primers)
Resource Information
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pHybr_r2a>Fab-srt-his was a gift from Ferenc Scheeren & Martijn Verdoes (Addgene plasmid # 124810 ; http://n2t.net/addgene:124810 ; RRID:Addgene_124810) -
For your References section:
Functional diversification of hybridoma-produced antibodies by CRISPR/HDR genomic engineering. van der Schoot JMS, Fennemann FL, Valente M, Dolen Y, Hagemans IM, Becker AMD, Le Gall CM, van Dalen D, Cevirgel A, van Bruggen JAC, Engelfriet M, Caval T, Bentlage AEH, Fransen MF, Nederend M, Leusen JHW, Heck AJR, Vidarsson G, Figdor CG, Verdoes M, Scheeren FA. Sci Adv. 2019 Aug 28;5(8):eaaw1822. doi: 10.1126/sciadv.aaw1822. eCollection 2019 Aug. 10.1126/sciadv.aaw1822 PubMed 31489367
