Myo1E-pEGFP
(Plasmid #124658)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 124658 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pEGFP-C1
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Myo1e
  • Alt name
    Myosin-1e
  • Species
    M. musculus (mouse)
  • GenBank ID
    BC051391.1
  • Entrez Gene
    Myo1e (a.k.a. 2310020N23Rik, 9130023P14Rik, AA407778, myosin-1e, myr 3)
  • Tag / Fusion Protein
    • EGFP (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site SalI (unknown if destroyed)
  • 5′ sequencing primer CMV-F
  • 3′ sequencing primer SV40-R
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Myo1E-pEGFP was a gift from Cheng-han Yu (Addgene plasmid # 124658 ; http://n2t.net/addgene:124658 ; RRID:Addgene_124658)
  • For your References section:

    Tail domains of myosin-1e regulate phosphatidylinositol signaling and F-actin polymerization at the ventral layer of podosomes. Zhang Y, Cao F, Zhou Y, Feng Z, Sit B, Krendel M, Yu CH. Mol Biol Cell. 2019 Mar 1;30(5):622-635. doi: 10.1091/mbc.E18-06-0398. Epub 2019 Jan 2. 10.1091/mbc.E18-06-0398 PubMed 30601698
