pTU-B-005
(Plasmid #124413)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 124413 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pET
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    slot B with sfGFP-MarAn20 reporter + terminator + spacer

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

GenBank file with original annotations can be downloaded from the "Resource Information" section. Please visit https://www.biorxiv.org/content/10.1101/611574v1 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTU-B-005 was a gift from Yolanda Schaerli (Addgene plasmid # 124413 ; http://n2t.net/addgene:124413 ; RRID:Addgene_124413)

  • For your References section:

    A Framework for the Modular and Combinatorial Assembly of Synthetic Gene Circuits. Santos-Moreno J, Schaerli Y. ACS Synth Biol. 2019 Jul 19;8(7):1691-1697. doi: 10.1021/acssynbio.9b00174. Epub 2019 Jun 24. 10.1021/acssynbio.9b00174 PubMed 31185158
