STING-V1
(Plasmid #124262)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 124262 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCDNA3
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    TMEM173
  • Alt name
    STING
  • Alt name
    NET23
  • Species
    H. sapiens (human)
  • Entrez Gene
    STING1 (a.k.a. ERIS, MITA, MPYS, NET23, SAVI, STING, STING-beta, TMEM173, hMITA, hSTING)
  • Tag / Fusion Protein
    • Venus1 (C terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    STING IMAGE clone came from RZPD - German Science Centre for Genome Research in 2004. Split Venus plasmids (V1/V2) were a gift from Patrick Heun 2018 (WCCB, Edinburgh)
  • Articles Citing this Plasmid

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    STING-V1 was a gift from Eric Schirmer (Addgene plasmid # 124262 ; http://n2t.net/addgene:124262 ; RRID:Addgene_124262)
