mNG-mTq2
(Plasmid
#124217)
-
PurposeCytoplasmic mNeongreen mTurquoise2 tandem, ~60 % energy transfer. pNM043 - pSAV057-mNG-mTq2
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 124217 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepSAV057
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Chloramphenicol, 25 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Growth instructionsAdd 0.5% glucose to repress expression
-
Copy numberLow Copy
Gene/Insert
-
Gene/Insert namemNG-mTq2
-
Alt namepNM043
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please Note: mNeonGreen contains a M1-N9 amino acid deletion that allows for better expression
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
mNG-mTq2 was a gift from Tanneke den Blaauwen (Addgene plasmid # 124217 ; http://n2t.net/addgene:124217 ; RRID:Addgene_124217) -
For your References section:
Superfolder mTurquoise2(ox) optimized for the bacterial periplasm allows high efficiency in vivo FRET of cell division antibiotic targets. Meiresonne NY, Consoli E, Mertens LMY, Chertkova AO, Goedhart J, den Blaauwen T. Mol Microbiol. 2019 Apr;111(4):1025-1038. doi: 10.1111/mmi.14206. Epub 2019 Feb 28. 10.1111/mmi.14206 PubMed 30648295
