GFP-TMCC2
(Plasmid #121047)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 121047 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pAcGFP1-C1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4700
  • Total vector size (bp) 6849
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Trans membrane and coiled coil domain containing protein 2
  • Alt name
    TMCC2
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    2130
  • GenBank ID
    NM_014858.4
  • Entrez Gene
    TMCC2 (a.k.a. HUCEP11)
  • Promoter CMV
  • Tag / Fusion Protein
    • GFP (N terminal on backbone)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer ATG AAG AGG TGC AGA TCG GAC G
  • 3′ sequencing primer GCT GGG CAG CAA CAC GTG CTC CAG GAG GTA G
    • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    GFP-TMCC2 was a gift from Gia Voeltz (Addgene plasmid # 121047 ; http://n2t.net/addgene:121047 ; RRID:Addgene_121047)

  • For your References section:

    A Novel Class of ER Membrane Proteins Regulates ER-Associated Endosome Fission. Hoyer MJ, Chitwood PJ, Ebmeier CC, Striepen JF, Qi RZ, Old WM, Voeltz GK. Cell. 2018 Sep 20;175(1):254-265.e14. doi: 10.1016/j.cell.2018.08.030. Epub 2018 Sep 13. 10.1016/j.cell.2018.08.030 PubMed 30220460
