Addgene

T16m
(Plasmid #121035)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 121035 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    DVA
  • Backbone size w/o insert (bp) 2100
  • Vector type
    Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    JM109
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    L3S2P55 (synthetic Voigt terminator)
  • Species
    Synthetic
  • Insert Size (bp)
    70

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer AAATAGGCGTATCACGAGGCA
  • 3′ sequencing primer TTACCGCCTTTGAGTGAGCTG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    T16m was a gift from Richard Murray (Addgene plasmid # 121035 ; http://n2t.net/addgene:121035 ; RRID:Addgene_121035)
