pHH04_32_sRNA-A_Sp_coD
(Plasmid
#120900)
-
Purposethe component plasmid of a regulated device
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 120900 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backboneColE2 plasmid
-
Vector typeBacterial Expression, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Spectinomycin, 50 μg/mL
-
Growth Temperature30°C
-
Growth Strain(s)DH5alpha
-
Copy numberUnknown
Gene/Insert 1
-
Gene/Insert namepECF32 promoter [i.e., Pecf32_1122 (-60 to -1)]
-
Insert Size (bp)60
Gene/Insert 2
-
Gene/Insert namesRNA-A
-
Insert Size (bp)113
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pHH04_32_sRNA-A_Sp_coD was a gift from Domitilla Del Vecchio (Addgene plasmid # 120900 ; http://n2t.net/addgene:120900 ; RRID:Addgene_120900) -
For your References section:
A quasi-integral controller for adaptation of genetic modules to variable ribosome demand. Huang HH, Qian Y, Del Vecchio D. Nat Commun. 2018 Dec 21;9(1):5415. doi: 10.1038/s41467-018-07899-z. 10.1038/s41467-018-07899-z PubMed 30575748
Map uploaded by the depositor.
