Addgene

pAL612
(Plasmid #119860)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 119860 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pET503
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    30°C
  • Growth Strain(s)
    MM52
  • Growth instructions
    Change media and shift temperature to 39 degrees with IPTG added to produce the precursor proteins
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    outer membrane protein A, ompA, with mutations Cysterine 290 to Serine and Glycine 244 to Cysteine
  • Alt name
    con; ECK0948; tolG; tut
  • Species
    Escherichia coli str. K-12
  • Insert Size (bp)
    1041
  • Mutation
    Cysterine 290 to Serine and Glycine 244 to Cysteine
  • GenBank ID
    945571
  • Promoter lac
  • Tag / Fusion Protein
    • none

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer 5' - GGGCGATATTACTGCACC - 3'
  • 3′ sequencing primer unknown
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Donald B. Oliver at Wesleyan University

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAL612 was a gift from Linda Randall (Addgene plasmid # 119860 ; http://n2t.net/addgene:119860 ; RRID:Addgene_119860)
  • For your References section:

    Co-assembly of SecYEG and SecA fully restores the properties of the native translocon. Bariya P, Randall LL. J Bacteriol. 2018 Oct 1. pii: JB.00493-18. doi: 10.1128/JB.00493-18. 10.1128/JB.00493-18 PubMed 30275279
