PYL1_nPPVp
(Plasmid #119211)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 119211 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3
  • Backbone size w/o insert (bp) 5446
  • Total vector size (bp) 6381
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    split nPPVp in fusion with PYL1
  • Alt name
    PYL1_nPPVp
  • Promoter CMV
  • Tag / Fusion Protein
    • AU1 tag (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (unknown if destroyed)
  • 3′ cloning site XhoI (unknown if destroyed)
  • 5′ sequencing primer CGCAAATGGGCGGTAGGCGTG
  • 3′ sequencing primer TAGAAGGCACAGTCGAGG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PYL1_nPPVp was a gift from Roman Jerala (Addgene plasmid # 119211 ; http://n2t.net/addgene:119211 ; RRID:Addgene_119211)

  • For your References section:

    Design of fast proteolysis-based signaling and logic circuits in mammalian cells. Fink T, Lonzaric J, Praznik A, Plaper T, Merljak E, Leben K, Jerala N, Lebar T, Strmsek Z, Lapenta F, Bencina M, Jerala R. Nat Chem Biol. 2019 Feb;15(2):115-122. doi: 10.1038/s41589-018-0181-6. Epub 2018 Dec 10. 10.1038/s41589-018-0181-6 PubMed 30531965
