cycLuc_TEVS
(Plasmid #119207)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 119207 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3
  • Backbone size w/o insert (bp) 5446
  • Total vector size (bp) 7780
  • Vector type
    Mammalian Expression, Luciferase

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    cyclic luciferase with TEVs cleavage site
  • Alt name
    cycLuc_TEVs
  • Insert Size (bp)
    2298
  • Promoter CMV
  • Tags / Fusion Proteins
    • AU1 tag (N terminal on insert)
    • 6xHis (N terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer CGCAAATGGGCGGTAGGCGTG
  • 3′ sequencing primer TAGAAGGCACAGTCGAGG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    cycLuc_TEVS was a gift from Roman Jerala (Addgene plasmid # 119207 ; http://n2t.net/addgene:119207 ; RRID:Addgene_119207)

  • For your References section:

    Design of fast proteolysis-based signaling and logic circuits in mammalian cells. Fink T, Lonzaric J, Praznik A, Plaper T, Merljak E, Leben K, Jerala N, Lebar T, Strmsek Z, Lapenta F, Bencina M, Jerala R. Nat Chem Biol. 2019 Feb;15(2):115-122. doi: 10.1038/s41589-018-0181-6. Epub 2018 Dec 10. 10.1038/s41589-018-0181-6 PubMed 30531965
