pNLuc
(Plasmid #118058)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 118058 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pUPD3
  • Backbone manufacturer
    Self made; Derived from pBluescriptSK
  • Backbone size w/o insert (bp) 2343
  • Total vector size (bp) 2680
  • Modifications to backbone
    Chloramphenicol Resistance
  • Vector type
    Luciferase, Synthetic Biology ; GBPart

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Nano Luciferase
  • Alt name
    NanoLuc
  • Alt name
    NLuc
  • Species
    Synthetic; Directed evolved synthetic, from Oplophorus gracilirostris. Promega.
  • Insert Size (bp)
    517

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BsmBI (destroyed during cloning)
  • 3′ cloning site BsmBI (destroyed during cloning)
  • 5′ sequencing primer tctatagtgtcacctaaat
  • 3′ sequencing primer taatacgactcactatagg
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Insert can be released with BsaI

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pNLuc was a gift from Koen Venken (Addgene plasmid # 118058 ; http://n2t.net/addgene:118058 ; RRID:Addgene_118058)
  • For your References section:

    Examining multiple cellular pathways at once using multiplex hextuple luciferase assaying. Sarrion-Perdigones A, Chang L, Gonzalez Y, Gallego-Flores T, Young DW, Venken KJT. Nat Commun. 2019 Dec 13;10(1):5710. doi: 10.1038/s41467-019-13651-y. 10.1038/s41467-019-13651-y PubMed 31836712
