pKEW189-MBP-TEV-AcrVA1
(Plasmid #115660)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 115660 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    2CT
  • Backbone manufacturer
    UC Berkeley
  • Backbone size w/o insert (bp) 5900
  • Total vector size (bp) 6486
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    AcrVA1
  • Species
    Moraxella bovoculi
  • Insert Size (bp)
    525
  • GenBank ID
    WP_046701302.1
  • Promoter T7 RNAP
  • Tag / Fusion Protein
    • MBP-TEV (N terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer CGCAGACTAATTCGAGCTCGAAC
  • 3′ sequencing primer GCTAGTTATTGCTCAGCGG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pKEW189-MBP-TEV-AcrVA1 was a gift from Jennifer Doudna (Addgene plasmid # 115660 ; http://n2t.net/addgene:115660 ; RRID:Addgene_115660)

  • For your References section:

    Systematic discovery of natural CRISPR-Cas12a inhibitors. Watters KE, Fellmann C, Bai HB, Ren SM, Doudna JA. Science. 2018 Oct 12;362(6411):236-239. doi: 10.1126/science.aau5138. Epub 2018 Sep 6. 10.1126/science.aau5138 PubMed 30190307
