pAAV-UbC-mCherry Rab5
(Plasmid #115239)

• Purpose: To express in mammalian cells the endocytic protein Rab5 fused to mCherry by transfection or by generating AAV virions.
• Depositing Lab: Pantelis Tsoulfas
• Publication: Eukaryotic expression plasmids for expression and visualization of early endocytic markers Rab5 and Rab7 (unpublished)

Want a viral vector made from this plasmid?

Make a packaging request and we'll get back to you.

This service is available to academics and nonprofits only.

Please log in to submit a packaging request.

• Serotype: Select serotype for details See details about
• Pricing: Select serotype and quantity $ USD for preparation of µL virus + $30 USD for plasmid.
• How this works:
  • Place a request for a quantity of 10 (1 mL), 25 (2.5 mL), or 50 (5 mL). Our all-inclusive pricing includes DNA production and QC.
  • Addgene will quickly confirm that we can produce a high-quality prep for you.
  • Track your request and place an order from within your account. Payment information must be added before we can begin processing your order.
  • Receive your prep in 6–9 weeks after the MTA is approved by your organization.
  • Learn more about our Packaged on Request Service.

Backbone

• Vector backbone: pAAV-SIBR-anti_I
• Backbone manufacturer: Chung K-H et al., Polycistronic RNA polymerase II expression vectors for RNA interference based on BIC/miR-155. NAR 2006 vol 24
• Backbone size w/o insert (bp): 5235
• Total vector size (bp): 6575
• Modifications to backbone: The anti-luciferase SIBR and eGFP sequence was deleted from the original backbone and new polylinker was created in the place of eGFP.
• Vector type: Mammalian Expression, AAV

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): NEB Stable
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: Rab5a
• Alt name: NP_004153.2
• Species: H. sapiens (human); Homo sapiens
• Insert Size (bp): 1340
• GenBank ID: NP_004153.2
• Entrez Gene: RAB5A (a.k.a. RAB5)
• Promoter: Human UbC
• Tag / Fusion Protein:
  • mCherry (N terminal on insert)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: NheI (destroyed during cloning)
• 3′ cloning site: NotI (destroyed during cloning)
• 5′ sequencing primer: pCAG_F_primer

Resource Information

• Article Citing this Plasmid:
  • 1 Reference

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
  • Takara Bio Limited Use Label License (formerly Clontech)
• Industry Terms:
  • Not Available to Industry

Depositor Comments

Note: Plasmid contains a mutation that removes the first nine amino acids of mCherry. This mutation is not known to affect plasmid function.
