OmpA3-PNGaseF-TEV-His6
(Plasmid #114274)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 114274 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pBluescript KS(-)
  • Backbone manufacturer
    Stratagene
  • Backbone size w/o insert (bp) 3000
  • Modifications to backbone
    Modification of plasmid #40315: Insertion of a TEV cleavage site between the hexaHis and the PNGase sequence to remove hexa-His
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Growth instructions
    DH5alpha (storage), BL21(DE3) (expression)
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Peptide: N-glycosidase F
  • Alt name
    PNGase F
  • Species
    Flavobacterium meningosepticum
  • Promoter T7
  • Tags / Fusion Proteins
    • OmpA3 leader sequence (for periplasmic localisation) (N terminal on insert)
    • hexa-Histidine tag with TEV cleavage site (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site unknown (unknown if destroyed)
  • 3′ cloning site unknown (unknown if destroyed)
  • 5′ sequencing primer unknown
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    OmpA3-PNGaseF-TEV-His6 was a gift from Martin Caffrey (Addgene plasmid # 114274 ; http://n2t.net/addgene:114274 ; RRID:Addgene_114274)
