pCAGGS_AKAR5’
(Plasmid
#114141)
-
PurposeMammalian expression of the AKAR5’ sensor for detecting PKA activity using two-photon fluorescence lifetime imaging microscopy (2pFLIM)
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 114141 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepCAGGS
- Backbone size w/o insert (bp) 5900
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameAKAR5'
-
SpeciesSynthetic
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pCAGGS_AKAR5’ was a gift from Haining Zhong (Addgene plasmid # 114141 ; http://n2t.net/addgene:114141 ; RRID:Addgene_114141) -
For your References section:
Liberated PKA Catalytic Subunits Associate with the Membrane via Myristoylation to Preferentially Phosphorylate Membrane Substrates. Tillo SE, Xiong WH, Takahashi M, Miao S, Andrade AL, Fortin DA, Yang G, Qin M, Smoody BF, Stork PJS, Zhong H. Cell Rep. 2017 Apr 18;19(3):617-629. doi: 10.1016/j.celrep.2017.03.070. 10.1016/j.celrep.2017.03.070 PubMed 28423323
