pcDNA5-FRT/TO-eGFP-SHLD3
(Plasmid
#114125)
-
PurposeExpresses N-terminally tagged eGFP-SHLD3 in mammalian cells
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 114125 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepcDNA5-FRT/TO-eGFP
- Backbone size w/o insert (bp) 5804
- Total vector size (bp) 6551
-
Vector typeMammalian Expression ; Genomic integration, tetracycline inducible
-
Selectable markersHygromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameSHLD3
-
Alt nameCTC543A2.2
-
Alt nameRINN1
-
SpeciesH. sapiens (human)
-
Insert Size (bp)747
-
Entrez GeneSHLD3 (a.k.a. CTC-534A2.2, RINN1)
- Promoter CMV/TetO2
-
Tag
/ Fusion Protein
- eGFP (N terminal on backbone)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site AscI (not destroyed)
- 3′ cloning site XhoI (not destroyed)
- 5′ sequencing primer EGFP-C
- 3′ sequencing primer BGH Reverse (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pcDNA5-FRT/TO-eGFP-SHLD3 was a gift from Daniel Durocher (Addgene plasmid # 114125 ; http://n2t.net/addgene:114125 ; RRID:Addgene_114125) -
For your References section:
The shieldin complex mediates 53BP1-dependent DNA repair. Noordermeer SM, Adam S, Setiaputra D, Barazas M, Pettitt SJ, Ling AK, Olivieri M, Alvarez-Quilon A, Moatti N, Zimmermann M, Annunziato S, Krastev DB, Song F, Brandsma I, Frankum J, Brough R, Sherker A, Landry S, Szilard RK, Munro MM, McEwan A, Goullet de Rugy T, Lin ZY, Hart T, Moffat J, Gingras AC, Martin A, van Attikum H, Jonkers J, Lord CJ, Rottenberg S, Durocher D. Nature. 2018 Aug;560(7716):117-121. doi: 10.1038/s41586-018-0340-7. Epub 2018 Jul 18. 10.1038/s41586-018-0340-7 PubMed 30022168
