pcDNA3.1-CAG-NanoLuc-VChR1-EYFP
(Plasmid #114112)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 114112 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone size w/o insert (bp) 6233
  • Total vector size (bp) 8547
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert 1

  • Gene/Insert name
    NanoLuc
  • Alt name
    NLuc
  • Species
    Oplophorous
  • Insert Size (bp)
    510

Gene/Insert 2

  • Gene/Insert name
    Volvox channelrhodopsin 1
  • Alt name
    VChr1

Gene/Insert 3

  • Gene/Insert name
    Enhanced Yellow Fluorescent Protein
  • Alt name
    EYFP

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1-CAG-NanoLuc-VChR1-EYFP was a gift from Ute Hochgeschwender (Addgene plasmid # 114112 ; http://n2t.net/addgene:114112 ; RRID:Addgene_114112)

  • For your References section:

    Luminopsins integrate opto- and chemogenetics by using physical and biological light sources for opsin activation. Berglund K, Clissold K, Li HE, Wen L, Park SY, Gleixner J, Klein ME, Lu D, Barter JW, Rossi MA, Augustine GJ, Yin HH, Hochgeschwender U. Proc Natl Acad Sci U S A. 2016 Jan 19;113(3):E358-67. doi: 10.1073/pnas.1510899113. Epub 2016 Jan 5. 10.1073/pnas.1510899113 PubMed 26733686
