pENTR-R4R3-mRuby-C
(Plasmid #113755)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 113755 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pDONR221-P4rP3r
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 2540
  • Vector type
    CRISPR ; Gateway Entry Vector

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    mRuby2
  • Insert Size (bp)
    723
  • Tag / Fusion Protein
    • mRuby2 (C terminal on insert)

Cloning Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Second position vector for three-way Gateway LR reaction to insert C-terminal mRuby2 at your locus of interest.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pENTR-R4R3-mRuby-C was a gift from Magdalena Bezanilla (Addgene plasmid # 113755 ; http://n2t.net/addgene:113755 ; RRID:Addgene_113755)

  • For your References section:

    Efficient and modular CRISPR-Cas9 vector system for Physcomitrella patens. Mallett DR, Chang M, Cheng X, Bezanilla M. Plant Direct. 2019 Sep 12;3(9):e00168. doi: 10.1002/pld3.168. eCollection 2019 Sep. 10.1002/pld3.168 PubMed 31523744
