pDuEx2-NIR-GECO1
(Plasmid #113680)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 113680 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pcDNA
  • Backbone size w/o insert (bp) 6160
  • Total vector size (bp) 7648
  • Vector type
    Mammalian Expression, Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    NIR-GECO1
  • Species
    Synthetic
  • Insert Size (bp)
    1488
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site HindIII (not destroyed)
  • 5′ sequencing primer CMV-F
  • 3′ sequencing primer CCA TGG AGT GGG ATT TTT TC
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pDuEx2-NIR-GECO1 was a gift from Robert Campbell (Addgene plasmid # 113680 ; http://n2t.net/addgene:113680 ; RRID:Addgene_113680)
  • For your References section:

    A genetically encoded near-infrared fluorescent calcium ion indicator. Qian Y, Piatkevich KD, Mc Larney B, Abdelfattah AS, Mehta S, Murdock MH, Gottschalk S, Molina RS, Zhang W, Chen Y, Wu J, Drobizhev M, Hughes TE, Zhang J, Schreiter ER, Shoham S, Razansky D, Boyden ES, Campbell RE. Nat Methods. 2019 Feb;16(2):171-174. doi: 10.1038/s41592-018-0294-6. Epub 2019 Jan 21. 10.1038/s41592-018-0294-6 PubMed 30664778
