Addgene

CH192
(Plasmid #113607)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 113607 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    psc101
  • Backbone size w/o insert (bp) 5239
  • Total vector size (bp) 5993

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    PIq:luxR
  • Promoter Iq

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ sequencing primer ctcatttctgaagaggacttgttg
  • 3′ sequencing primer gacagcggtgcggactgttgtaactcagaataag
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    CH192 was a gift from Matthew Bennett (Addgene plasmid # 113607 ; http://n2t.net/addgene:113607 ; RRID:Addgene_113607)

  • For your References section:

    Tuning the dynamic range of bacterial promoters regulated by ligand-inducible transcription factors. Chen Y, Ho JML, Shis DL, Gupta C, Long J, Wagner DS, Ott W, Josic K, Bennett MR. Nat Commun. 2018 Jan 4;9(1):64. doi: 10.1038/s41467-017-02473-5. 10.1038/s41467-017-02473-5 PubMed 29302024
