pXPR_053
(Plasmid #113591)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 113591 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pLX_TRC931
  • Backbone manufacturer
    Broad Institute
  • Backbone size w/o insert (bp) 5180
  • Total vector size (bp) 7664
  • Modifications to backbone
    (1) Introduction of sgRNA cloning cassette (2) Removal of LacI-2A sequence (3) Replacement of GFP with Vex (4) Mutation of additional BsmBI cloning sites (outside sgRNA cloning cassette)
  • Vector type
    Mammalian Expression, Lentiviral, CRISPR
  • Selectable markers
    Vex fluorescence

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Growth instructions
    NA
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    sgRNA cloning site
  • gRNA/shRNA sequence
    NA
  • Promoter U6

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BsmBI (destroyed during cloning)
  • 3′ cloning site BsmBI (destroyed during cloning)
  • 5′ sequencing primer GTGAATAGAGTTAGGCAGGGATATTCACC
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pXPR_053 was a gift from Arlene Sharpe (Addgene plasmid # 113591 ; http://n2t.net/addgene:113591 ; RRID:Addgene_113591)

  • For your References section:

    A CRISPR-Cas9 delivery system for in vivo screening of genes in the immune system. LaFleur MW, Nguyen TH, Coxe MA, Yates KB, Trombley JD, Weiss SA, Brown FD, Gillis JE, Coxe DJ, Doench JG, Haining WN, Sharpe AH. Nat Commun. 2019 Apr 10;10(1):1668. doi: 10.1038/s41467-019-09656-2. 10.1038/s41467-019-09656-2 PubMed 30971695
