pBP-PliaG
(Plasmid
#112777)
-
PurposeWeak constitutive promoter of liaGFSR operon involved in detection of cell wall damage
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 112777 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepSB1C3
-
Backbone manufactureriGEM
- Backbone size w/o insert (bp) 2115
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Chloramphenicol, 25 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namePliaG promoter
-
Alt nameBBa_K143012
-
SpeciesSynthetic
-
Insert Size (bp)121
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site Bsa1 (unknown if destroyed)
- 3′ cloning site Bsa1 (unknown if destroyed)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please visit https://www.biorxiv.org/content/early/2017/09/06/185108 for bioRxiv preprint.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pBP-PliaG was a gift from Chris French (Addgene plasmid # 112777 ; http://n2t.net/addgene:112777 ; RRID:Addgene_112777) -
For your References section:
BacilloFlex: A modular DNA assembly toolkit for Bacillus subtilis synthetic biology. Wicke N, Radford D, Verrone V, Wipat A, French CE. bioRxiv 185108 10.1101/185108
