pHES945
(Plasmid #112643)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 112643 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pSV605
  • Backbone size w/o insert (bp) 8200
  • Total vector size (bp) 10200
  • Vector type
    Yeast Expression
  • Selectable markers
    LEU2

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CRY2PHR-GAL4DBD
  • Species
    S. cerevisiae (budding yeast), A. thaliana (mustard weed)
  • Promoter TDH3

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (destroyed during cloning)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer CTATATTAGCTTGTGCATTCGCATG
  • 3′ sequencing primer ATC GCA CTC ACG TAA ACA CTT
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pHES945 was a gift from Hana El-Samad (Addgene plasmid # 112643 ; http://n2t.net/addgene:112643 ; RRID:Addgene_112643)

  • For your References section:

    Real-Time Genetic Compensation Defines the Dynamic Demands of Feedback Control. Harrigan P, Madhani HD, El-Samad H. Cell. 2018 Oct 18;175(3):877-886.e10. doi: 10.1016/j.cell.2018.09.044. 10.1016/j.cell.2018.09.044 PubMed 30340045
