pGEX Rad C249
(Plasmid #11228)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 11228 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pGEX-2T
  • Backbone manufacturer
    Amersham
  • Backbone size w/o insert (bp) 4950
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Rad
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    800
  • Mutation
    C249: deletion of amino acids 249-308
  • Entrez Gene
    RRAD (a.k.a. RAD, RAD1, REM3)
  • Tag / Fusion Protein
    • GST (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer pGEX5'
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The C249 mutant contains a deletion of the calmodulin binding site.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pGEX Rad C249 was a gift from Ronald Kahn (Addgene plasmid # 11228 ; http://n2t.net/addgene:11228 ; RRID:Addgene_11228)
  • For your References section:

    Rad and Rad-related GTPases interact with calmodulin and calmodulin-dependent protein kinase II. Moyers JS, Bilan PJ, Zhu J, Kahn CR. J Biol Chem. 1997 May 2. 272(18):11832-9. 10.1074/jbc.272.18.11832 PubMed 9115241
