pONSY-Lifeact:mCherry
(Plasmid #111876)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 111876 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pONSY
  • Backbone size w/o insert (bp) 5127
  • Modifications to backbone
    Capsaspora expression vector (backbone) modified from the pCR2.1 vector. It bears the promoter and terminator regions from the endogenous Elongation Factor 1 alpha (EF1a) gene (CAOG_07807) cloned using Restriction Enzymes and Gibson Assembly strategies.
  • Vector type
    Capsaspora owczarzaki

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin and Kanamycin, 100 & 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Lifeact fused to mCherry
  • Insert Size (bp)
    780
  • Promoter Elongation Factor 1 alpha (EF1a) from Capsaspora
  • Tag / Fusion Protein
    • mCherry (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XmaI (not destroyed)
  • 3′ cloning site XbaI (destroyed during cloning)
  • 5′ sequencing primer CCCGGGACCATGGGTGTGGCAGACCTGATTAAGAAGTTCGAGAGCATT
  • 3′ sequencing primer TCTAGATGGTGGGTCACCCTCCTCCTTGCTAATGCTCTCGAACTTCTT
  • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pONSY-Lifeact:mCherry was a gift from Inaki Ruiz-Trillo (Addgene plasmid # 111876 ; http://n2t.net/addgene:111876 ; RRID:Addgene_111876)
  • For your References section:

    Transfection of Capsaspora owczarzaki, a close unicellular relative of animals. Parra-Acero H, Ros-Rocher N, Perez-Posada A, Kozyczkowska A, Sanchez-Pons N, Nakata A, Suga H, Najle SR, Ruiz-Trillo I. Development. 2018 May 11. pii: dev.162107. doi: 10.1242/dev.162107. 10.1242/dev.162107 PubMed 29752387
