His-ZZ-TEV-BICDN(1-400)-GFP
(Plasmid #111862)

• Purpose: C-terminal GFP tag on BICDN (amino acids 1-400) for baculovirus expression in Sf9 cells. 8xHis-ZZ N-terminal tag, TEV site to cleave 8xHis-ZZ.
• Depositing Lab: Andrew Carter
• Publication: Urnavicius et al Nature. 2018 Feb 7;554(7691):202-206. doi: 10.1038/nature25462.

Backbone

• Vector backbone: pOmnibac
• Backbone size w/o insert (bp): 4500
• Total vector size (bp): 6947
• Vector type: Insect Expression
• Selectable markers: Gentamicin

Growth in Bacteria

• Bacterial Resistance(s): Gentamicin, 10 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: BICDN(1-400)-GFP
• Species: M. musculus (mouse)
• Insert Size (bp): 2400
• Mutation: Codon optimized for Sf9 expression
• GenBank ID: NM_029791.4
• Entrez Gene: Bicd2
• Tags / Fusion Proteins:
  • 8xHis tag (N terminal on insert)
  • ZZ tag (N terminal on insert)
  • GFP (C terminal on insert)

Resource Information

• Supplemental Documents:
  • p1539 ZZ-LTL-BICD2N-1_400-GFP.gb
• Article Citing this Plasmid:
  • 1 Reference

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Depositor Comments

Please note that there are some discrepancies between Addgene's quality control sequence and the depositor's sequence. The depositor noted that these discrepancies do NOT affect plasmid function.
