KG#470
(Plasmid #110930)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 110930 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pUC
  • Backbone size w/o insert (bp) 2632
  • Total vector size (bp) 4930
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert 1

  • Gene/Insert name
    rab-3 promoter
  • Species
    C. elegans (nematode)
  • Insert Size (bp)
    1208

Cloning Information for Gene/Insert 1

Gene/Insert 2

  • Gene/Insert name
    unc-54 3' control region
  • Species
    C. elegans (nematode)
  • Insert Size (bp)
    940

Cloning Information for Gene/Insert 2

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Unique multi-cloning sites: Nhe I, Sbf I, Kpn I/ Age I/ Xho I, Bgl II

This vector is the same as KG#59, except the Sal I and Acc I sites of the multi-cloning site have been replaced with a Sbf I site.

Synthesized 2 complementary oligos containing Nhe I and Age I sticky ends and Sbf I and Kpn I sites in between. Hybridization of the 2 oligos to each other will produce Nhe I and Age I sticky ends. After hybridization, this synthetic insert (which is non-phosphorylated on its 5' termini) was cloned into Nhe I/ Age I cut KG#59. Transformed into XL1-Blue electrocompetent cells. Miniprepped 6 clones and tested for the Sbf I site by cutting with Sbf I. Chose one clone that has the Sbf I site with correct band size (and only a single band) and made the glycerol stock.

Features of the expression construct: This expression construct has a promoter (rab-3) that will drive strong and specific expression (of whatever gene is inserted in the MCS) in the entire nervous system of juvenile and adult animals. The boundaries of the rab-3 promoter sequence were obtained by examining pRabGFPrim3' from Mike Nonet's lab web site and comparing that to the genome sequence. Other features of the expression vector include a "decoy" 5' to the promoter to reduce non-specific expression in the gut (see Fire Lab 1995 Kit documentation for description), the unc-54 3' end including the poly A addition signal, and 3 introns (1 in 5' UTR, 1 just upstream of the unc-54 3' end, and 1 inserted in the unc-54 3' end). These introns help provide more uniform and robust expression, especially if you are expressing a cDNA with no introns as opposed to a gene with introns.

Note: this vector can be converted to a vector that fuses GFP, YFP, or CFP onto the C-terminus of the protein as follows:

Remove the ~1000 bp (Kpn I or Age I) + (Spe I or BsiW I [expensive, 55 C cutter with 50% activity at 37 C; heat inactivate 80 C] or Apa I) fragment containing the unc-54 3’ control region from this plasmid and replace it with the ~1800 bp like-digested fragment containing 3-intron S65C GFP (see pPD94.81 in Fire Lab plasmids), YFP (see pPD136.64 in Fire Lab plasmids) or CFP (see pPD136.61 in Fire Lab plasmids) + the unc-54 3’ UTR and control region. Note if Spe I is used to cut these Fire Lab vectors, you get 3 bands: 1100, 1800, and 4000 (total size 6.9 Kb). The 1800 bp band is the XFP-containing band.

For C-terminal fusions, remember to leave the stop codon off of the upstream protein. For the above-mentioned Fire Lab vectors, the reading frame for the downstream XFP relative to the Kpn I and Age I sites is as follows (triplets are the reading frame codons):

Kpn I
G GTA CCG GT
Age I

Alternatively, use Gibson Assembly/ NEBuilder to insert any genetically encoded fluorescent protein at the N- or C-terminus of your protein.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    KG#470 was a gift from Kenneth Miller (Addgene plasmid # 110930 ; http://n2t.net/addgene:110930 ; RRID:Addgene_110930)
  • For your References section:

    Mutations that rescue the paralysis of Caenorhabditis elegans ric-8 (synembryn) mutants activate the G alpha(s) pathway and define a third major branch of the synaptic signaling network. Schade MA, Reynolds NK, Dollins CM, Miller KG. Genetics. 2005 Feb;169(2):631-49. doi: 10.1534/genetics.104.032334. Epub 2004 Oct 16. 10.1534/genetics.104.032334 PubMed 15489510
