pBXNPHM3
(Plasmid #110099)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 110099 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pBXNPHM3
  • Vector type
    Bacterial Expression
  • Tag / Fusion Protein
    • His (N terminal on backbone)

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol and Ampicillin, 25 & 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    ccdB Survival
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    None
  • Tag / Fusion Protein
    • His (N terminal on backbone)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBXNPHM3 was a gift from Markus Seeger (Addgene plasmid # 110099 ; http://n2t.net/addgene:110099 ; RRID:Addgene_110099)
  • For your References section:

    Synthetic single domain antibodies for the conformational trapping of membrane proteins. Zimmermann I, Egloff P, Hutter CA, Arnold FM, Stohler P, Bocquet N, Hug MN, Huber S, Siegrist M, Hetemann L, Gera J, Gmur S, Spies P, Gygax D, Geertsma ER, Dawson RJ, Seeger MA. Elife. 2018 May 24;7. pii: 34317. doi: 10.7554/eLife.34317. 10.7554/eLife.34317 PubMed 29792401
