pLenti-LbCpf1-U6_FlipArray
(Plasmid #109349)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 109349 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pY109
  • Backbone manufacturer
    Feng Zhang
  • Backbone size w/o insert (bp) 12630
  • Total vector size (bp) 12720
  • Modifications to backbone
    Modified U6 expression casette to be used for FlipArray.
  • Vector type
    Mammalian Expression, Lentiviral, Cre/Lox, CRISPR, Synthetic Biology
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    U6-FlipArray
  • Alt name
    U6-DR-lox66-DR-BsmbIx2-lox71'-6T
  • Species
    Synthetic
  • Insert Size (bp)
    137
  • Promoter U6

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer gagggcctatttcccatgat
  • 3′ sequencing primer gggacagcagagatccagtttggT
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLenti-LbCpf1-U6_FlipArray was a gift from Sidi Chen (Addgene plasmid # 109349 ; http://n2t.net/addgene:109349 ; RRID:Addgene_109349)
  • For your References section:

    Programmable sequential mutagenesis by inducible Cpf1 crRNA array inversion. Chow RD, Kim HR, Chen S. Nat Commun. 2018 May 15;9(1):1903. doi: 10.1038/s41467-018-04158-z. 10.1038/s41467-018-04158-z PubMed 29765043
