nuc-gTEMP_pcDNA3
(Plasmid #109118)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 109118 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3
  • Backbone manufacturer
    Invitrogen
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    nuc-gTEMP
  • Alt name
    Nucleus targetting gTEMP
  • Species
    Synthetic
  • Insert Size (bp)
    2283
  • GenBank ID
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site HindIII (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer GCTAACTAGAGAACCCACTGCTTAC
  • 3′ sequencing primer TAGAAGGCACAGTCGAGG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    nuc-gTEMP_pcDNA3 was a gift from Takeharu Nagai (Addgene plasmid # 109118 ; http://n2t.net/addgene:109118 ; RRID:Addgene_109118)

  • For your References section:

    Genetically encoded ratiometric fluorescent thermometer with wide range and rapid response. Nakano M, Arai Y, Kotera I, Okabe K, Kamei Y, Nagai T. PLoS One. 2017 Feb 17;12(2):e0172344. doi: 10.1371/journal.pone.0172344. eCollection 2017. PONE-D-16-44541 [pii] PubMed 28212432
