PurposeBacterial Target-AID vector
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 108549 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepSC101
- Backbone size w/o insert (bp) 9263
- Total vector size (bp) 10758
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Chloramphenicol, 25 μg/mL
-
Growth Temperature30°C
-
Growth Strain(s)DH5alpha
-
Growth instructionsTransformed cells grow slow and colony formation takes 2 days. Do not pick larger colonies as escape cells may appear.
-
Copy numberLow Copy
Gene/Insert
-
Gene/Insert namedCas9-PmCDA1
-
SpeciesSynthetic; Streptococcus pyogenes
-
Insert Size (bp)7252
-
MutationD10A and H840A for SpCas9
-
GenBank IDOYN72315.1 ABO15149.1
- Promoter lambda OR
-
Tag
/ Fusion Protein
- Flag
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer M13F
- 3′ sequencing primer cgtggatccggcttact (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pScI_dCas9-CDA was a gift from Akihiko Kondo (Addgene plasmid # 108549 ; http://n2t.net/addgene:108549 ; RRID:Addgene_108549) -
For your References section:
Deaminase-mediated multiplex genome editing in Escherichia coli. Banno S, Nishida K, Arazoe T, Mitsunobu H, Kondo A. Nat Microbiol. 2018 Feb 5. pii: 10.1038/s41564-017-0102-6. doi: 10.1038/s41564-017-0102-6. 10.1038/s41564-017-0102-6 [pii] PubMed 29403014
