UBQ10:sXVE:ATG-3xHA-S11
(Plasmid #108238)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 108238 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    UBQ10:sXVE:GFPc:Kan
  • Backbone manufacturer
    Jörg Kudla
  • Total vector size (bp) 14561
  • Vector type
    Plant Expression, Synthetic Biology
  • Selectable markers
    Kanamycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    ATG-3xHA-S11
  • Species
    Synthetic
  • Insert Size (bp)
    201
  • Promoter UBQ10:sXVE:

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XbaI (unknown if destroyed)
  • 3′ cloning site SacI (unknown if destroyed)
  • 5′ sequencing primer cttcgcaagacccttcc
  • 3′ sequencing primer TCGCGTATTAAATGTATAATTGCGGGACTC
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    UBQ10:sXVE:ATG-3xHA-S11 was a gift from Tzu-Yin Liu (Addgene plasmid # 108238 ; http://n2t.net/addgene:108238 ; RRID:Addgene_108238)

  • For your References section:

    Detection of membrane protein-protein interaction in planta based on dual intein-coupled tripartite split-GFP association. Liu TY, Chou WC, Chen WY, Chu CY, Dai CY, Wu PY. Plant J. 2018 Feb 16. doi: 10.1111/tpj.13874. 10.1111/tpj.13874 PubMed 29451720
