PurposeExpresses dLbCpf1-eBE in mammalian cells
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 107688 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backboneCMV
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namedLbCpf1-eBE
-
Alt namepCMV-SV40NLS-APOBEC1-XTEN-dLbCpf1(D832A/E1006A/D1125A)-SV40NLS-SGGS-UGI-SV40NLS-T2A-UGI-SV40NLS-P2A-UGI-SV40NLS-T2A-UGI-SV40NLS
-
SpeciesR. norvegicus (rat); Lachnospiraceae bacterium, Bacteriophage PBS2
-
Insert Size (bp)5757
-
MutationdLbCpf1(D832A/E925A/D1148A)
- Promoter CMV
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer CMV
- 3′ sequencing primer BGH poly reverse (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
-
A portion of this plasmid was derived from a plasmid made byderived from plasmid pCMV-BE3 (David Liu, Addgene plasmid # 73021)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
derived from plasmid pCMV-BE3 (David Liu, Addgene plasmid # 73021)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pCMV-dCpf1-eBE was a gift from Jia Chen (Addgene plasmid # 107688 ; http://n2t.net/addgene:107688 ; RRID:Addgene_107688) -
For your References section:
Base editing with a Cpf1-cytidine deaminase fusion. Li X, Wang Y, Liu Y, Yang B, Wang X, Wei J, Lu Z, Zhang Y, Wu J, Huang X, Yang L, Chen J. Nat Biotechnol. 2018 Mar 19. pii: nbt.4102. doi: 10.1038/nbt.4102. 10.1038/nbt.4102 PubMed 29553573
