pUBC_V5_MS2-mVenus
(Plasmid
#107606)
-
PurposeTransient expression of humanized MS2 (V75E/A81G), fused to mVenus in mammalian cells, under a hUBC promoter, V5 tag
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 107606 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepNEB193
-
Vector typeSynthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameMS2-mVenus
-
SpeciesSynthetic
-
MutationMS2: V75E/A81G
- Promoter human UBC
-
Tags
/ Fusion Proteins
- mVenus (C terminal on insert)
- V5 (N terminal on insert)
Cloning Information
- Cloning method Ligation Independent Cloning
- 5′ sequencing primer M13F
- 3′ sequencing primer M13R (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pUBC_V5_MS2-mVenus was a gift from John Rinn (Addgene plasmid # 107606 ; http://n2t.net/addgene:107606 ; RRID:Addgene_107606) -
For your References section:
Spatiotemporal allele organization by allele-specific CRISPR live-cell imaging (SNP-CLING). Maass PG, Barutcu AR, Shechner DM, Weiner CL, Mele M, Rinn JL. Nat Struct Mol Biol. 2018 Jan 8. pii: 10.1038/s41594-017-0015-3. doi: 10.1038/s41594-017-0015-3. 10.1038/s41594-017-0015-3 [pii] PubMed 29343869
