pCSD_2xNLS-SpCas9MT3-NLS-3xHA-NLS-dSaCas9-2xNLS
(Plasmid #107318)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 107318 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCSDest2
  • Total vector size (bp) 11753
  • Vector type
    Mammalian Expression, CRISPR

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    SpCas9-SaCas9 fusion
  • Species
    Synthetic; S. pyogenes, S. aureus
  • Insert Size (bp)
    7668
  • Mutation
    SpCas9 (R1335K) fused to nuclease dead SaCas9 (D10A, N580A)
  • Promoter CMV IE94
  • Tags / Fusion Proteins
    • NLS (N terminal on insert)
    • NLS (C terminal on insert)

Cloning Information

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCSD_2xNLS-SpCas9MT3-NLS-3xHA-NLS-dSaCas9-2xNLS was a gift from Scot Wolfe (Addgene plasmid # 107318 ; http://n2t.net/addgene:107318 ; RRID:Addgene_107318)

  • For your References section:

    Orthogonal Cas9-Cas9 chimeras provide a versatile platform for genome editing. Bolukbasi MF, Liu P, Luk K, Kwok SF, Gupta A, Amrani N, Sontheimer EJ, Zhu LJ, Wolfe SA. Nat Commun. 2018 Nov 19;9(1):4856. doi: 10.1038/s41467-018-07310-x. 10.1038/s41467-018-07310-x PubMed 30451839
