hACTB-RFP-Kir7.1
(Plasmid #107179)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 107179 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pRP[Exp]-Bsd
  • Backbone manufacturer
    Vector Builder
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    KCNJ13
  • Species
    H. sapiens (human)
  • GenBank ID
    NM_002242.4
  • Entrez Gene
    KCNJ13 (a.k.a. KIR1.4, KIR7.1, LCA16, SVD)
  • Promoter hACTB
  • Tag / Fusion Protein
    • RFP (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site unknown (unknown if destroyed)
  • 3′ cloning site unknown (unknown if destroyed)
  • 5′ sequencing primer NA
  • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    hACTB-RFP-Kir7.1 was a gift from Bikash Pattnaik (Addgene plasmid # 107179 ; http://n2t.net/addgene:107179 ; RRID:Addgene_107179)
