Purposemammalian expression
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 107153 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepCDNA4
-
Backbone manufacturerThermo Fisher Scientific
-
Vector typeMammalian Expression
-
Selectable markersZeocin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameVinculin
-
Alt nameVCL
-
SpeciesH. sapiens (human)
-
Insert Size (bp)3201
-
Entrez GeneVCL (a.k.a. CMD1W, CMH15, HEL114, MV, MVCL, VINC)
- Promoter CMV
-
Tag
/ Fusion Protein
- (His)10-GFP (N terminal on backbone)
Cloning Information
- Cloning method Gibson Cloning
Resource Information
-
Addgene Notes
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
GFP tag in frame with metavinculin gene
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pcDNA4-GFP-Vinculin was a gift from Tina Izard (Addgene plasmid # 107153 ; http://n2t.net/addgene:107153 ; RRID:Addgene_107153) -
For your References section:
Lipid binding promotes oligomerization and focal adhesion activity of vinculin. Chinthalapudi K, Rangarajan ES, Patil DN, George EM, Brown DT, Izard T. J Cell Biol. 2014 Dec 8;207(5):643-56. doi: 10.1083/jcb.201404128. 10.1083/jcb.201404128 PubMed 25488920
