pZA-YFP-R5
(Plasmid #106257)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 106257 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pZA31
  • Backbone manufacturer
    expressys
  • Backbone size w/o insert (bp) 2828
  • Total vector size (bp) 2009
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    Yellow fluorescent protein
  • Alt name
    YFP
  • Insert Size (bp)
    819
  • Promoter pL-TetO
  • Tag / Fusion Protein
    • Added silaffin R5 peptide to C terminus of YFP after 3xGGGGS linker (C terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer AAATACGCCCGGTAGTGATCTT
  • 3′ sequencing primer GGCCCTCTCACTTCCCTGTTAA
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pZA-YFP-R5 was a gift from Urartu Seker (Addgene plasmid # 106257 ; http://n2t.net/addgene:106257 ; RRID:Addgene_106257)

  • For your References section:

    Autonomous Synthesis of Fluorescent Silica Biodots Using Engineered Fusion Proteins. Olmez TT, Yuca E, Eyupoglu E, Catalak HB, Sahin O, Seker UOS. ACS Omega. 2018 Jan 31;3(1):585-594. doi: 10.1021/acsomega.7b01769. Epub 2018 Jan 18. 10.1021/acsomega.7b01769 PubMed 30023783
