pcDNA3.1/V5-His-TN-DROSHA
(Plasmid #106252)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 106252 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pcDNA3/V5-His
  • Backbone manufacturer
    invitrogen
  • Backbone size w/o insert (bp) 5514
  • Total vector size (bp) 9533
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    30°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Drosha Ribonuclease III
  • Alt name
    Drosha
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    4017
  • Mutation
    E1045Q and E1222Q mutations
  • GenBank ID
    NM_001100412
  • Entrez Gene
    DROSHA (a.k.a. ETOHI2, HSA242976, RANSE3L, RN3, RNASE3L, RNASEN)
  • Promoter CMV
  • Tag / Fusion Protein
    • V5-His (C terminal on insert)

Cloning Information

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    pcDNA4/TO/cmycDrosha (Thomas Tuschl)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please note that DROSHA mutation numbering (E1045Q and E1222Q) is modeled on Heo et al., Mol Cell 32: 276–284. These mutations correspond to E1008Q and E1185Q in this construct. In addition, a series of silent mutations across bp 1203 - 1221render the encoded DROSHA mRNA resistant to siRNAs that target that site.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1/V5-His-TN-DROSHA was a gift from Joshua Mendell (Addgene plasmid # 106252 ; http://n2t.net/addgene:106252 ; RRID:Addgene_106252)
  • For your References section:

    Genome-wide annotation of microRNA primary transcript structures reveals novel regulatory mechanisms. Chang TC, Pertea M, Lee S, Salzberg SL, Mendell JT. Genome Res. 2015 Sep;25(9):1401-9. doi: 10.1101/gr.193607.115. 10.1101/gr.193607.115 PubMed 26290535
