pcDNA3.1/V5-His-TN-DROSHA
(Plasmid
#106252)
-
PurposeExpress TN-DROSHA in mammalian cells
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 106252 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepcDNA3/V5-His
-
Backbone manufacturerinvitrogen
- Backbone size w/o insert (bp) 5514
- Total vector size (bp) 9533
-
Vector typeMammalian Expression
-
Selectable markersNeomycin (select with G418)
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature30°C
-
Growth Strain(s)NEB Stable
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameDrosha Ribonuclease III
-
Alt nameDrosha
-
SpeciesH. sapiens (human)
-
Insert Size (bp)4017
-
MutationE1045Q and E1222Q mutations
-
GenBank IDNM_001100412
-
Entrez GeneDROSHA (a.k.a. ETOHI2, HSA242976, RANSE3L, RN3, RNASE3L, RNASEN)
- Promoter CMV
-
Tag
/ Fusion Protein
- V5-His (C terminal on insert)
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer CMV forward
- 3′ sequencing primer BGH reverse (Common Sequencing Primers)
Resource Information
-
A portion of this plasmid was derived from a plasmid made bypcDNA4/TO/cmycDrosha (Thomas Tuschl)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please note that DROSHA mutation numbering (E1045Q and E1222Q) is modeled on Heo et al., Mol Cell 32: 276–284. These mutations correspond to E1008Q and E1185Q in this construct. In addition, a series of silent mutations across bp 1203 - 1221render the encoded DROSHA mRNA resistant to siRNAs that target that site.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pcDNA3.1/V5-His-TN-DROSHA was a gift from Joshua Mendell (Addgene plasmid # 106252 ; http://n2t.net/addgene:106252 ; RRID:Addgene_106252) -
For your References section:
Genome-wide annotation of microRNA primary transcript structures reveals novel regulatory mechanisms. Chang TC, Pertea M, Lee S, Salzberg SL, Mendell JT. Genome Res. 2015 Sep;25(9):1401-9. doi: 10.1101/gr.193607.115. 10.1101/gr.193607.115 PubMed 26290535
