pFA6a-kanMX6-P41nmt1-mECitrine
(Plasmid #105152)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 105152 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pFA6a
  • Backbone size w/o insert (bp) 4170
  • Vector type
    Bacterial Expression, Yeast Expression
  • Selectable markers
    KanMX6 (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    kanMX6-P41nmt1-mECitrine
  • Alt name
    monomeric enhanced Citrine
  • Alt name
    41nmt1
  • Species
    S. pombe (fission yeast)
  • Insert Size (bp)
    1900
  • Mutation
    F64L, Q69M, A206K
  • Promoter 41nmt1
  • Tag / Fusion Protein
    • 41nmt1-mECitrine (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site PacI (not destroyed)
  • 3′ cloning site AscI (not destroyed)

Resource Information

  • Supplemental Documents

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The sizes of backbone and inserts are approximate, and do not include the selectable marker.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pFA6a-kanMX6-P41nmt1-mECitrine was a gift from Jian-Qiu Wu (Addgene plasmid # 105152 ; http://n2t.net/addgene:105152 ; RRID:Addgene_105152)
  • For your References section:

    The novel proteins Rng8 and Rng9 regulate the myosin-V Myo51 during fission yeast cytokinesis. Wang N, Lo Presti L, Zhu YH, Kang M, Wu Z, Martin SG, Wu JQ. J Cell Biol. 2014 May 12;205(3):357-75. doi: 10.1083/jcb.201308146. Epub 2014 May 5. 10.1083/jcb.201308146 PubMed 24798735
